AT 3018 Absolute length gauge HEIDENHAIN-ACANTO Plunger actuation: Extended by spring force Measuring length: 30 mm Type of guide: sliding glide Accuracy grade: 2.0 µm Electrical connection: Flange socket M12, male, 8-pin Pin configuration: D532351 Data interface: Synchronous serial EnDat 2.2 without incremental signals Measuring step: 368 nm Power supply: 3.6 V ... 14 V Degree of protection: IP67 (EN60529) Operating temperature: +10/+40 °C
