编码器 768295-11 ECN 1313 512 62S12-78
编码器 S D1 1131753-01 ROQ 425 512 01 -E0
模块 671566-01 UM 115D
编码器 376836-28 ROD 436 2000 27S12-03
长度计 383979-01 ST 1288 12-pin male 90°出线 IP64
读数头 315420-04 AE LB 382C
长度计 243602-06 MT 12
光栅尺 689697-09 LC 185 940 5,0
光栅尺 689697-06 LC 185 640 5,0
光栅尺 689697-11 LC 185 1140 5,0
光栅尺 689697-07 LC 185 740 5,0
ECN 1313 Rotary encoder with integral bearing Positions per revolution: 8192 Data interface: EnDat01 Output code: Binary Line count: 512 Output signal: ~1Vpp Cutoff frequency (-3 dB): 130.00 kHz Power supply: 3.6 V ... 14 V Coupling version: Expanding ring coupling for 65mm mating diameter Shaft: Tapered shaft 1 to 10, functional diameter 9.25 mm, back-off thread M10 and M6 Degree of protection: IP40 (EN60529) Operating temperature: -40/+115 °C Electrical connection: Plug connector, straight, double-row, 12-pin, with locking mechanism and walls Pin configuration: D323746 Connecting direction: Cable outlet for axial and radial use Included part: self-locking screw M5 x50 -8.8 DIN 6912 Please pay attention to the product documentation!
