RCN 8580 Absolute angle encoder (singleturn) with integral bearing and integrated stator coupling System accuracy: ±1.0'' Data interface: EnDat02 Positions per revolution: 536870912 Output code: Binary Line count: 32768 Output signal: ~1Vpp Cutoff frequency (-3 dB): 400.00 kHz Power supply: 3.6 V ... 14 V Shaft: Hollow shaft, diameter 60 mm Flange version: 54C Degree of protection: IP64 (EN60529) Operating temperature: 0/+50 °C Max. mechanical permissible speed/rotational speed: 500 1/min Electrical connection: Flange socket Ultra-Lock, male, 12-pin Pin configuration: D629024 Connecting direction: tangential Special characteristics, rotational encoders: none
LC 193F/50nm ML 140mmID 557676-01
LC 193F/50nm ML 240mmID 557676-02
LC 193F/50nm ML 340mmID 557676-03
LC 193F/50nm ML 440mmID 557676-04
LC 193F/50nm ML 540mmID 557676-05
LC 193F/50nm ML 640mmID 557676-06
LC 193F/50nm ML 740mmID 557676-07
