HEIDENHAIN 751363-01,751363-01圆光栅,751363-01技术参数资料
751363-01 型号名描述：
| Part number ID | 751363-01 |
| Description | RCN 2390F Absolute angle encoder (singleturn) with integral bearing and integrated stator coupling System accuracy: ±5.0'' Data interface: Fanuc05 Positions per revolution: 67108864 Output code: Dual Power supply: 3.6 V ... 14 V Shaft: Hollow through shaft for axial clamping, diameter 20 mm Flange version: Rectangular flange with 85 mm centering collar, drainage channels, aluminum Degree of protection: IP 64 (EN 60529) Operating temperature: -20/+60 °C Max. mechanical permissible speed/rotational speed: 1500 1/min Electrical connection: Flange socket Ultra-Lock, male, 12-pin Pin configuration: D680849 Connecting direction: tangential Special characteristics, rotational encoders: none |
ID 751363-01
描述RCN 2390F绝对角度编码器（单圈），带集成轴承和集成定子联轴器
系统精度：±5.0
数据接口：Fanuc05
每转的位置：67108864
输出代码：双
电源：3.6 V ... 14 V
轴：空心通孔，用于轴向夹紧，直径20 mm
法兰版本：矩形法兰，带85 mm的定心环，排水通道，铝
防护等级：IP 64（EN 60529）
工作温度：-20 / + 60°C
最高 机械
允许速度/转速：1500 1 / min
电气连接：法兰插座Ultra-Lock，公头，12针引脚配置：D680849
