WMKA 2010HA High Accuracy Scanning head for modular angle encoders Scanning arrangement: Outside scanning Measuring method: absolute Measuring principle: inductive Design of the scanning Standard, cable outlet head: right Line count: 512 Interface: EnDat 2.2 Ordering designation: EnDat22 Interpolation factor digital: 14 Bit Positions per revolution: 8388608 (23 bit) Incremental signals: without Number of signal periods: 0 Grating period: 1000 µm Incremental signals / multiplication: no incremental signals Max. scanning frequency: 20.00 kHz Power supply: 3.6 V ... 14 VDC Electrical connection: Coupling M12, male, 8-pin Pin configuration: D532351 Cable length: 3.00 m
