MT 1281 02S12 03 ~1Vss 01 .. 1,50 01 1,7mm 50 ES 2,000 KF 01 0,2
MT 1281 Incremental length gauge HEIDENHAIN-METRO Plunger actuation: Extended by spring force Measuring length: 12 mm Type of guide: ball guide Reference mark position:1.7mm Accuracy grade: 0.2 µm Electrical connection: Connector M23, male, 12-pin Pin configuration: D294999 Cable type: PUR Ø 4.5 mm Cable length: 1.50 m> Output signal: sinusoidal voltage signals (1 Vpp) Grating period: 4.000 µm Power supply: 5V+-5% Degree of protection: IP 50 (EN 60529) Operating temperature: +10/+40 °C
